Dumper Box Structure: The Dumper Box is primarily designed with lightweight construction, with options for rectangular or square structures. The mining dumper truck uses high-strength, wear-resistant steel boxes.
Hydraulic Lifting System: Hydraulic pump, distribution valve, lifting cylinder, and oil pipes. Mining trucks use multi-stage double top or side top structures for heavy-duty impact resistance.
Chassis and Load-Bearing Structure: The chassis is welded from high-strength alloy steel, with reinforced main and sub-beams to distribute stress. The suspension system and lifting devices are integrated into key points of the chassis. Mining chassis are equipped with anti-torsion box beams and tubular rear crossbeams to ensure reliability in long-term heavy-duty operations.
| SPECIFICATION | ||
| Truck Specification | ||
| Product Name | Tipper dump truck | |
| Chassis Specification | ||
| Chassis brand | Dongfeng, Shacman, Foton, Sinotruk Howo, ISUZU, FAW, NORTH BENZ, JAC, CAMC, IVECO | |
| Drive type | 4X2, 6X4, 8X4, 4X4, 6X6, 8X8 | |
| Engine brand | Cummins, ISUZU, Wechai, Yuchai, Yunnei | |
| Transmission brand | Fast, ZF, Manual/ATM | |
| Tire brand | Tri-angle, Double Coin, Good year, Michelin | |
| Upper body specification | ||
| Dumper box | Capacity | 5ton, 10ton, 15ton, 20ton, 25ton, 30ton, 35ton, 40ton, 50ton, 60ton, 70ton |
| Tank Material | Q235 Carbon steel, Q345 16Mn steel, HARDOX 400 steel | |
| Function | Equipped with hydraulic lifting cylinders, main brands: HYVA | |
| Equipped with different size cylinder with Φ90, Φ100, Φ160, Φ180, Φ220, Φ169, Φ191 | ||
| Equipped with hydraulic front lifting cylinders, side lifting cylinders or middle lifting cylinders. It can meet customer's different requests. | ||
| The dumper box has different design shapes (light "U" shape, Strengthen square shape). | ||
| Equipped with hydraulic automatic operation. | ||
Hydraulic system of the dump truck adopts efficient hydraulic pumps and cylinders to deliver powerful lifting force;
The cargo body structure is rationally designed with high-quality steel plates, particularly ensuring high strength and compression resistance; U-shaped cargo bodies are especially critical in mining transportation, enabling greater material capacity and improved transportation efficiency.
The chassis and load-bearing components adopt a reinforced design with high load-bearing capacity and durability, adapting to various working conditions to ensure operational stability and safety. Suitable for use in mining, construction projects, and sanitation operations.
