1. High design pressure of 1.5MPa to ensure safe storage of liquid chlorine.
2. Made of Q345R material with a wall thickness of 14mm and a head thickness of 16mm, offering excellent compression resistance and corrosion resistance.
3. International container standard size, compact dimensions for easy transport and storage.
| Specification | |
| Filling Medium | Liquid Chlorine |
| Design Pressure (MPa) | 1.5 |
| Hydrostatic Test Pressure (MPa) | 1.95 |
| Tank Inner Diameter (mm) | A 2250 |
| Tank Tare Weight (kg) | 7800 |
| Weld Joint Efficiency | 1.0 |
| Shell Wall Thickness (mm) | 14 |
| Design Temperature (℃) | 55 |
| Tank Material | Q345R |
| Size (FT) | 20 |
| Frame External Dimensions (mm) | 6058 × 2438 × 2591 |
| Max Filling Mass (kg) | 26691 |
| Corrosion Allowance (mm) | 4 |
| Head Wall Thickness (mm) | 16 |
| Container Code | 22K8 |
| Standard configuration | Tank Lining; Manhole; Feed Port; Breathing Valve; Discharge Port; Level Gauge; Discharge Hose; |
| Other Services | Customized LOGO design as per customer needs! |
