| Tank design code | ASME Vlll-1 Appendix 44 IMDG ADR/RID CSC | |||
| Classification Society | BV | |||
| Type | T75 UN Protable Tank | |||
| Frame work | ISO 1496 | |||
| Size and Type Code | 22K7 ISO 668 1CC | |||
| Nominal Capacity | 22,000L | |||
| MPMG | 36,000kg | |||
| Tare Mass | 8700kg | |||
| Stacking mass | 213360kg | |||
| Frame dimension(L*W*H) | 6058*2438*2591mm | |||
| Design Temperature | 50℃ | |||
| MDMT | -196℃ | |||
| Work Pressure | 2.2MPa | |||
| Test Pressure | 2.99MPa | |||
| Leakage Test pressure | 2.2MPa | |||
| Framework | Q355D(GB/T 1591) | |||
| Inner Vessel | SA-240M 304N | |||
| Outer Jacket | Q345R(GB/T 713) | |||
| Type of Insulation | High Vacuum Multi-Insulation | |||
| Insulation material | Aluminium Foil | |||
| Seal-off Vacuum Degree | 0.08MPa | |||
| Leak and outgassing rate | 1X10⁻⁶ Pa·m3/s | |||
| Degree of filling | 23095kg | |||
| Contents | LN2 | UN1977 | ||
| LO2 | UN1073 | |||
| LAr | UN1951 | |||
| LCO2 | UN2187 | |||
| LN2O | UN2201 | |||
| LNG | UN1972 | |||
| LC2H4 | UN1038 | |||
| Documentation | General Drawing; Storage Vessel Drawing; Inner Vessel Drawing; Instruction manual; Code Calculation Sheet; Certificate of quality; Certificate of safety attachment; | |||
