1. The tank body is made of Q235 carbon steel, with a 5mm cylinder body and 5.5mm head structure. The single-compartment design is combined with a 3-inch self-draining outlet and foldable guardrails, meeting international industry standard load and medium operation requirements.
2. The main welds are single-side welds with double-side forming (copper groove + ceramic pad process). After sandblasting and rust removal, the entire vehicle is coated with paint, with 30% improved adhesion and a corrosion resistance life of over 10 years.
3. The Fuhua 10-ton drum brake axle is adapted for the Comet ABS system, with 12.00R22.5 vacuum tires and 8-piece steel leaf springs. The total carrying capacity is 28 tons, and the braking efficiency is optimized by 15%.
Chassis | |
| Over Dimension(mm) | 11290×2500×3900 |
| Gross Vehicle Weight(kg) | 40000 |
| Curb Weight(kg) | 10000 |
| Loading Weight(kg) | 30000 |
| Tyre Qty. | 12 |
| Tyre Spec. | 11.00R20 12PR,12R22.5 12PR |
| Wheelbase（mm） | 5800+1310+1310 |
| Front/Rear Overhang (mm) | -/1525 |
| Approach/Departure angle(°) | -/18 |
| ABS | Included |
Upper Equipment | |
| Tank Capacity | 44.9 cbm/m³/cubic meter |
| Tank Dimension(mm) | 10800x2500x2170/1950 |
| Tank Material | Q235 Carbon steel |
| Tank Compartment Qty. | Single-chamber , Multi-chamber customizable |
| Tank Filling Medium | Fracturing fluid or well washing fluid |
| Tank Body Thikness(mm) | 5 |
| Tank End Cap(mm) | 5.5 |
| Wave board Thikness(mm) | 3.75 |
| Safety Valve | 2× Nomal Tank ports; 1× Bottom ports; 1× Voice prompt device; 2×3-inch self-flowing ports; |
| Standard Configuration | 10-ton Fuhua axles with matching air suspension; 50# Towing pin; 1×28-ton single-action support legs; 2×8 kg fire extinguishers; 1×Spare tire rack; 1×Toolbox 1×Ladder, tank top with folding guardrail, walking part |
| Other Services | Customized LOGO design as per customer needs! |
