1.MAWP 1.8 MPa, hydrostatically tested at 2.48 MPa for high safety.
2.Built with Q420DR vessel-grade steel, 11/12 mm thick with corrosion allowance.
3.ISO dimensions for seamless global intermodal logistics.
4.Supports custom logo and marking for international branding needs.
| Specification | |
| Filling Medium | LPG(Liquefied Petroleum Gas) |
| Size (FT) | 20 |
| Frame External Dimensions (mm) | 6058 × 2438 × 2591 |
| Container Code | 22KX |
| Capacity (m³) | 24 |
| Filling Density | 420 |
| Tank Tare Weight (kg) | 7720 |
| Allowable Filling Weight(kg) | 10080 |
| Tank Material | Q420DR |
| Design Pressure (MPa) | 1.8/-0.04 |
| Maxallowable Work Pressure (MPa) | 1.8 |
| Hydrostatic Test Pressure (MPa) | 2.41 |
| Weld Joint Efficiency | 1.0 |
| Shell/Head Thickness (mm) | 11/12 |
| Corrosion Allowance (mm) | 1 |
| Design Temperature (℃) | -40~50 |
| Other Services | Customized LOGO design as per customer needs! |
