1. Adopts Dongfeng chassis, 3.6-ton disc front axle, 10-ton Dana rear axle, with superior power.
2. Equipped with Fast 8JS95 gearbox (with flange-mounted PTO), 8-speed manual gearbox, featuring precise shifting and high transmission efficiency.
3. Tank capacity 2530L, aluminum alloy material. All main welds strictly follow NDT (non-destructive testing) procedures. Full vehicle paint coverage without blind spots or omissions.
4. Standard components: Arc gear pump (pumping in/out capable); single compartment (customizable to multiple compartments); Two EU-standard tank ports; one bottom valve; complete bottom loading system; full vehicle lightweight design.
5. Optional installations: Flow meter; high-flow fuel dispenser; 15-meter auto-rewind hose reel and fuel nozzle.
Chassis | |
| Brand | Dongfeng |
| Drive Type | 6×2,LHD/RHD |
| Gross Vehicle Weight(kg) | 25500 |
| Curb Weight(kg) | 8435 |
| Loading Weight(kg) | 16870 |
| Overall Dimension(mm) | 10280×2500×3460 |
| Tyre Qty. | 8 |
| Tyre Spec. | 295/80R22.5 18PR |
| Wheelbase（mm） | 1995+4200 |
| Front/Rear Overhang (mm) | 1515/2570,1475/2610,1540/2545 |
| Approach/Departure angle(°) | 29/10 |
| Fuel Type | Diesel |
| Maximum Speed (km/h) | 80 |
| ABS | Yes |
| Transmission | 8-speed |
| Steering | Power steering, hydraulic steering with power assistance |
| Cab | Accommodate 2-3 people |
Engine(Other Engines Optional) | |
| Brand | Yuchai |
| Model | YC6S06 245-60 |
| Power(kw) | 180 |
| Horsepower(HP) | 245 |
Upper Equipment | |
| Tank Capacity(cbm) | 25.3 |
| Tank Dimension(mm) | 7500×2480×1680mm |
| Tank Material | Aluminium alloy |
| Tank Compartment Qty. | Single-chamber (Multiple-chamber Optional) |
| Tank Filling medium | Diesel or gasoline |
| Standard Components | Pump with overflow valve; Two EU-standard tank ports; One bottom valve; Voice prompt alarm system; Aset of bottom loading and vapor recovery system; One toolbox; Safety guardrail; Rear access ladder; Two oil delivery hoses; Two fire extinguishers. |
| Optional Components | Flow meter, high-flow fuel dispenser, 15-meter auto-rewind hose reel, and fuel nozzle |
| Other Services | Customized LOGO design as per customer needs! |
