1. Utilizes a bilateral loading/unloading + dual valve box structure; single liquid outlet with dual valves in series to reduce leakage risks; safety valve and emergency shut-off valve linkage ensures dual protection through overpressure release and emergency shutoff.
2. 13-ton Fuhua axle + leaf spring suspension, paired with 12.00R22.5 tubeless tires for stable load-bearing; iron fenders and anti-static tape guard against mechanical damage and electrostatic sparks.
3. Q345R carbon steel tank body integrates pressure gauge and thermometer for real-time monitoring; LED lights enhance nighttime warnings; fire extinguisher + anti-static grounding strip create dual safeguards against fire and static hazards.
4. Dual tool boxes separate maintenance tools and emergency supplies; Fuhua outriggers, 90# traction pins, compatible with mainstream truck heads; support legs improve stability and safety during hitching/unhitching operations.
Specification | |
| Over Dimension(mm) | 12900×2500×3980 |
| Gross Vehicle Weight(kg) | 40000 |
| Curb Weight(kg) | 15430 |
| Loading Weight(kg) | 24570 |
| Tyre Qty. | 12 |
| Tyre Spec. | 12R22.5 12PR |
| Wheelbase（mm） | 7092+1310+1310 |
| Tank Capacity | 58.5CMB/58.5m³/58500 liter/58.5cubic meter |
| Tank Dimension(mm) | 2475×12×12607 |
| Tank Material | Q345R carbon steel |
| Tank Compartment Qty. | Single-chamber |
| Tank Thickness(mm) | 14 |
| Designed Pressure(MPa) | 1.61 |
| Filling Factor | 0.95 |
| Filling Ratio(ton/cbm) | 0.42 |
| Working Temperature(℃) | <50 |
| Tank Filling Medium | LPG |
| Corrosion Allowance(mm) | 1 |
| Standard configuration | Single liquid outlet, bilateral loading/unloading, dual valve boxes, dual tool boxes, safety valve, thermometer, pressure gauge, emergency shut-off valve, 13-ton Fuhua axle, leaf springs, iron wheel rims, iron fenders, Fuhua support legs with 90 kingpin, fire extinguisher, anti-static grounding tape, LED lights. |
| Other Services | Customized LOGO design as per customer needs! |
