1. Foton chassis, equipped with a powerful Cummins 160-horsepower engine and 8-speed gearbox, delivering outstanding heavy-duty performance.
2. Double-layer frame with 4 mm steel plates and U-channel steel durable structure ensures stability under a 4-ton load.
3. Flexible rescue system with hydraulic telescopic/tilting platform (5.4~5.5 meters) and 4-ton winch, suitable for various towing scenarios.
4. ABS anti-lock braking system, spring brake, and reinforced radial tires enhance operational safety.
Chassis | |
| Brand | Foton |
| Drive Type | Left hand drive/4x2 |
| Gross Vehicle Weight(kg) | 4495 |
| Curb Weight(kg) | 2800 |
| Loading Weight(kg) | 1500 |
| Overall Dimension(mm) | 5995×2300×2315 |
| Tyre Qty. | 6 |
| Tyre Spec. | 7.00R16LT 8PR |
| Wheelbase（mm） | 3600 |
| Front/Rear Overhang (mm) | 1110/1285 |
| Front/Rear Track (mm) | 1600/1590 |
| Approach/Departure angle(°) | 14/17 |
| Fuel Type | Diesel |
| Maximum Speed (km/h) | 105 |
| ABS | Included |
| Transmission | Fast 8-speed manual gearbox |
| Steering | Power steering, hydraulic steering with power assistance |
| Cab | 3-seater |
| Frame | Double-layer reinforced frame |
Engine (Other Engine Optional) | |
| Brand | Cummins |
| Model | F2.5NS6B172 |
| Power(kw) | 120 |
| Horsepower(HP) | 163 |
Upper & Equipment | |
| Load Capacity | 4-ton heavy-duty design |
| Flatbed Material | 4mm anti-slip checkered steel plate |
| Winch System | 4-ton hydraulic winch with 21m steel cable |
| Frame Reinforcement | Single sub-frame + U-shaped channel, reinforced crossbeams |
| Operating System | Bilateral linkage controls |
| Flatbed | - Total length: ~5.4m (3.8m + 1.6m) - Hydraulic flip plate: ~5.5m (4.1m + 1.4m) - Hydraulic telescopic plate: ~5.4m (4.2m + 1.2m) - Width: ~2.3m |
| Accessories | - 1 auxiliary trolley - 4 tie-down straps - 1 pair L-shaped towing forks - 1 pair rotating sleeves - Toolbox, warranty manual, certifications |
| Remarks | Customized LOGO design as per customer needs! |
