1. Purpose: It used for helicopter refueling and mobile transporting aviation kerosene.
2. Main parts: Fuel pump, flow meter and filling gun etc.
3. Especially suitable for refueling drones, helicopters, and various small aircraft.
Chassis | |
| Brand | Dongfeng |
| Drive Type | Left hand drive/4x2 |
| Gross Vehicle Weight(kg) | 7360 |
| Curb Weight(kg) | 3570 |
| Loading Weight(kg) | 3360 |
| Overall Dimension(mm) | 5995×2000×2680 |
| Tyre Qty. | 6 |
| Tyre Spec. | 7.00R16 14PR Steel-Belted Radial Tire |
| Wheelbase（mm） | 3308 |
| Front/Rear Overhang (mm) | 1055/1632 |
| Approach/Departure angle(°) | 28/13 |
| Fuel Type | Diesel |
| Maximum Speed (km/h) | 80 |
| ABS | Yes |
| Transmission | Manual type, 8 Forwards and 2 reverse |
| Steering | Power steering, hydraulic steering with power assistance |
| Cab | It can accommodate three people, With Air conditioner |
Engine | |
| Brand | Quanchai Power |
| Model | Q28-130E60 |
| Power(kw) | 96 |
| Horsepower(HP) | 130 |
| Emission standard | Euro 3 |
Upper & Equipment | |
| Tank Capacity(cbm) | 4.7 |
| Tank Material | Aluminium alloy |
| Tank Thickness(mm) | 5 |
| Tank Compartment Qty.(pcs) | 1 |
| Tank Filling medium | Aviation kerosene |
| Fuel Pump Model | China local brand |
| Fuel Pump Qty | 1 |
| Manhole on top tanker | European standard,including pressure relief valve |
| Safety Valve | European Standard |
| Discharge Valve | Alluminum Alloy Ball Valve type |
| Emergency Cutoff Device | Alluminum Alloy Bottom Valve |
| Oil Pump | aluminium alloy |
| Refueling reel | Aircraft refueling reel with refueling gun |
| Standard configuration | Roller shutter, filter, flow meter, instrument panel, electronic level gauge, stainless steel internal pipes, a tool box, and two fire extinguishers etc are included |
| Remarks | Customized LOGO design as per customer needs! |
