1. HOWO chassis with 338 kW CNHTC engine and long wheelbase.
2. 16-ton tank (12t water, 4t foam), anti-corrosion steel, reinforced structure.
3. Equipped with 60 L/s fire pump and ≥60 m range monitor, supports multiple water sources.
4. Six-seat cab with tilting, respirator system, and night lighting.
5. Features stainless level indicators, modular compartments, and reliable PTO cooling.
| Chassis | |
| Brand | HOWO |
| Drive Type | Left hand drive/6x4 |
| Gross Vehicle Weight(kg) | 31800 |
| Curb Weight(kg) | 15550 |
| Loading Weight(kg) | 15800 |
| Overall Dimension(mm) | 10170×2550×3570 |
| Tyre Qty. | 10 |
| Tyre Spec. | 385/65R22.5/12.00R20 18PR |
| Wheelbase（mm） | 4600+1400 |
| Front/Rear Overhang (mm) | 1500/2670 |
| Approach/Departure angle(°) | 15/9 |
| Fuel Type | Diesel |
| Maximum Speed (km/h) | 95 |
| ABS | Included |
| Cab | |
| Structure | Flat-head, original double-row four-door crew cab Equipped with a hydraulic tilting mechanism for easy cab tilting |
| Seating Arrangement | 2 seats in the front row, 4 seats in the rear row |
| In-Cab Equipment | A PTO control switch, 100W siren, and light switch are installed |
| Exterior of the Cab | One long light bar is mounted on the front section of the cab roof |
| Engine (Other Engine Optional) | |
| Brand | CNHTC Group |
| Model | MC11.46-61 |
| Power(kw) | 341 |
| Horsepower(HP) | 465 |
| Upper & Equipment | |
| Water Tank Capacity(kg) | 12000 |
| Foam Tank Capacity(kg) | 4000 |
| Water Tank Material | High-quality steel plate with advanced anti-corrosion treatment |
| Foam Tank Material | High-quality 304 stainless steel |
| Fire Tank Equipment | 2× manholes with quick-lock and release mechanisms 2× level indicators 2× drainage outlets with stainless steel ball valves 4× filling inlets (two on each side) |
| Fire Pump | CB10/60 Low-Pressure Fire Pump |
| Pump Flow Rate | 60 L/s |
| Pump Pressure | 1.0 MPa |
| Installation Type | Rear-mounted |
| Pump Type | Piston-type Vacuum Pump |
| Maximum Vacuum Degree | ≥85 kPa |
| Fire Monitor Model | PL8/48 Fire Monitor |
| Fire Monitor Flow Rate | 60 L/s |
| Fire Monitor Range | Water ≥ 60 m, Foam ≥ 55 m |
| Fire Monitor Pressure | 1.0 MPa |
| Fire Monitor Position | Mounted on top of the water tank |
| Fire Monitor Control | Manual control with locking mechanism for convenient operation |
| Remarks | Customized LOGO design as per customer needs! |
