Name: Dongfeng Hook Arm Garbage Truck
Brand: SHENZHEN VEHISION SPECIAL VEHICLE CO., LTD
Availability: InStock

Dongfeng Hook Arm Garbage Truck

1. The garbage truck adopts Dongfeng chassis, with hydraulic system composed of oil pump, multi-way valve, hydraulic cylinder, oil tank, etc., controlling lifting and dumping actions. Components use imported/domestic renowned brands, high stability with pressure set at 16Mpa.

2. Electrical control system integrates lifting/dumping operation, cabin lighting, and equipment power supply.

3. Dumping mechanism realizes cargo-box tilting via hydraulic drive, with tilting angle automatically controlled by the system.

4. Supports multi-container connection to reduce equipment configuration/space occupation. Optional 3-7m³ waste containers: domestic waste, heavy construction waste, industrial waste (specific type), compressed waste, corrosion-resistant containers.

Specification of Dongfeng Hook Arm Garbage Truck

Chassis

Brand

Dongfeng

Drive Type

4×2

Gross Vehicle Weight(kg)

18000

Curb Weight(kg)

7260

Loading Weight(kg)

10610

Overall Dimension(mm)

6500×2500×3100

Tyre Qty.

Tyre Spec.

7.00R16LT 8PR,6.50R16LT 10PR

Wheelbase（mm）

3950

Front/Rear Overhang (mm)

1260/1290

Approach/Departure angle(°)

19/20

Fuel Type

Diesel

Maximum Speed (km/h)

105

Transmission

6-speed

ABS

Yes

Cab

Accommodate 2-3 people,LHD/RHD

Engine(Other Engines Optional)

Brand

Cummins

Model

B6.2NS6B230

Power(kw)

169

Horsepower(HP)

230

Upper Equipment

Loading Capacity

10T

Dustbin Material

Anti-corrosive steel

Hydraulic System

Import or Chinese top brand muti-way valve and cylinders

Control Method

Manual control or remote control

Self-discharging Incline Angle(°)

Lifting Time(s)

≤60

Unloading Time(s)

≤60

Other Services

Customized LOGO design as per customer needs!

FAQs About Dongfeng Hook Arm Garbage Truck

What is a Dongfeng hook arm garbage truck used for?

A Dongfeng hook arm garbage truck is used for collecting and transporting detachable waste containers in municipal and industrial waste handling operations.

How does the hook arm system work on this garbage truck?

The hook arm system uses a hydraulic mechanism to hook, lift, and place waste containers onto and off the truck chassis for loading and unloading.

What types of containers can a hook arm garbage truck handle?

It is designed to work with compatible detachable waste containers that can be loaded and unloaded using the hook arm system.

Can a Dongfeng hook arm garbage truck be customized?

Yes, it can be configured based on operational requirements such as container compatibility, hydraulic system setup, and lifting capacity. In some cases, this type of configuration is referred to as a hook arm garbage truck solution.

How efficient is the loading and unloading process?

The loading and unloading process is designed for quick container handling using the hydraulic hook arm system, reducing manual operation during waste collection activities.
