1.Adopts Foton Aumark chassis, Cummins high-torque engine, with superior power.
2.Equipped with domestically renowned gearbox, featuring precise shifting and high transmission efficiency.
3.Tank capacity 12,380L, carbon steel material. The tank undergoes NDT (non-destructive testing) process, sandblasting, and baking paint finish for enhanced safety and durability.
4.Standard components: Pump with overflow valve; single compartment (customizable to multiple compartments); one EU-standard tank port; one bottom valve; voice prompt alarm system; complete bottom loading system; full vehicle lightweight design.
5.Optional installations: Flow meter; fuel dispenser; hose reel; and fuel nozzle.
Chassis | |
| Brand | Foton |
| Drive Type | Left hand drive/4x2 |
| Gross Vehicle Weight(kg) | 18000 |
| Curb Weight(kg) | 7800 |
| Loading Weight(kg) | 10005, 10070 |
| Overall Dimension(mm) | 8400×2530×3300 |
| Tyre Qty. | 6 |
| Tyre Spec. | 11R22.5 18PR |
| Wheelbase（mm） | 4700 |
| Front/Rear Overhang (mm) | 1270/2430 |
| Approach/Departure angle(°) | 18/11 |
| Fuel Type | Diesel |
| Maximum Speed (km/h) | 80 |
| ABS | Yes |
| Transmission | 6-speed |
| Steering | Power steering, hydraulic steering with power assistance |
| Cab | Accommodate 2-3 people |
Engine(Other Engines Optional) | |
| Brand | Cummins |
| Model | B6.2NS6B210 |
| Power(kw) | 154 |
| Horsepower(HP) | 210 |
Upper Equipment | |
| Tank Capacity(cbm) | 12.38 |
| Tank Dimension(mm) | 5750×2050×1380mm |
| Tank Material | Carbon steel |
| Tank Compartment Qty. | Single-chamber (Multiple-chamber Optional) |
| Tank Filling medium | Diesel or gasoline |
| Standard Components | 1×Pump with overflow valve; 1× EU-standard tank ports; 1× bottom valve; Voice prompt alarm system; 1×complete bottom loading system; 1× toolbox; 2× fire extinguishers. 1×Rear access ladder; Safety guardrail; |
| Optional Components | Flow meter, high-flow fuel dispenser, 15-meter auto-rewind hose reel, and fuel nozzle |
| Other Services | Customized LOGO design as per customer needs! |
