1. The 304 stainless steel tank body main welds undergo X-ray inspection, meeting industry standards. The single-side welding and double-side forming technique ensures zero leakage and safe medium transportation.
2. Sandblasting + baking paint process improves adhesion by 30%, with a corrosion-resistant lifespan exceeding 10 years. The entire vehicle is fully covered with paint, suitable for high-salinity corrosion environments.
3. 10-ton Fuhua axle + air suspension + EBS system, 28-ton single-acting leg + fiberglass walkway, lightweight bolt structure reduces weight by 15%, and is compressive at 300MPa.
Chassis | |
| Over Dimension(mm) | 11500×2500×3900 |
| Gross Vehicle Weight(kg) | 40000 |
| Curb Weight(kg) | 8200 |
| Loading Weight(kg) | 31800 |
| Tyre Qty. | 12 |
| Tyre Spec. | 12R22.5 12PR |
| Wheelbase（mm） | 5900+1310+1310 |
| Front/Rear Overhang (mm) | -/1600 |
| Approach/Departure angle(°) | -/18 |
Upper Equipment | |
| Tank Capacity(cbm) | 35.9 |
| Tank Dimension(mm) | Front:2950×1930, Rear: 7350×2180, |
| Tank Material | 304 Stainless steel |
| Tank Compartment Qty. | Single-chamber , Multi-chamber customizable |
| Tank Filling medium | Ammonia water |
| Safety Valve | 2× Stainless steel tank ports; 1× Stainless steel sea bottom value; 1× DN80 stainless steel outlet; 1× Voice prompt device; |
| Standard Configuration | 10-ton Fuhua axles with matching air suspension; Equipped with EBS; 50# Towing pin; 1×28-ton single-action support legs; 2×8 kg fire extinguishers; 1×Spare tire rack; 1×Toolbox |
| Other Services | Customized LOGO design as per customer needs! |
