1.Adopts FAW dangerous goods specialized chassis and FAWDE high-torque engine with ultra-high horsepower.
2.Equipped with a well-known domestic-brand gearbox featuring precise gear shifting and high transmission efficiency.
3.Tank capacity 2860L, aluminum alloy material. All main tank welds strictly welded following non-destructive testing procedures.
4.Standard components: arc gear pump; one overflow valve; one EU-standard tank port; one bottom valve with voice alarm; a right-side mounted bottom loading system; full vehicle lightweight design,flow meter, fuel dispenser, and hose reel.
Chassis | |
| Brand | FAW |
| Drive Type | Left hand drive/4x2 |
| Gross Vehicle Weight(kg) | 4495 |
| Curb Weight(kg) | 2455 |
| Loading Weight(kg) | 1910 |
| Overall Dimension(mm) | 5470×2000×2520,2460 |
| Tyre Qty. | 6 |
| Tyre Spec. | 7.00R16LT 8PR |
| Wheelbase（mm） | 2800 |
| Front/Rear Overhang (mm) | 1155/1515 |
| Approach/Departure angle(°) | 14/13 |
| Fuel Type | Diesel |
| Maximum Speed (km/h) | 79 |
| ABS | Yes |
| Transmission | 5-speed |
| Steering | Power steering, hydraulic steering with power assistance |
| Cab | Accommodate 2-3 people |
| Other Configuration | Electric central control with Power Windows & remote door locks electric air conditioning Dual warning system with tire burst emergency response |
Engine(Other Engines Optional) | |
| Brand | Xichai |
| Model | CA4DB1A14E68 |
| Power(kw) | 100 |
| Horsepower(HP) | 136 |
Upper Equipment | |
| Tank Capacity(cbm) | 2.86 |
| Tank Dimension(mm) | 3200×1320×910 |
| Tank Material | Aluminium alloy |
| Tank Compartment Qty. | Single-chamber design |
| Tank Filling medium | Aasoline |
| Standard Components | Arc gear pump 1× relief valve 1× European standard tank port 1× bottom loading valve (emergency shut-off) Voice alert module Bottom loading system (mounted on the right side) Flow meter,metering dispenser and hose reel |
| Other Services | Customized LOGO design as per customer needs! |
