1. Power & Efficiency
-Weichai 140HP engine paired with WLY 6-speed transmission ensures strong torque for heavy-duty operations while maintaining fuel efficiency.
2. Robust Build Quality
-180mm double-layer frame + 10mm sliding channels provide exceptional durability for heavy-load towing.
3. Versatile Functionality
-Integrated hydraulic system (winch, tilting, lifting) + optional rear tow arm adapts to diverse recovery scenarios.
4. User-Centric Design
-Ergonomic cab (multifunctional steering wheel, cruise control) and dual-side controls enhance operator safety and convenience .
5. Comprehensive Safety
-Air-spring parking brake, front counterweight, and reinforced straps secure stability during critical operations.
Chassis | |
| Brand | Sinotruk |
| Drive Type | Left hand drive/4x2 |
| Gross Vehicle Weight(kg) | 4495 |
| Curb Weight(kg) | 2800 |
| Loading Weight(kg) | 1500 |
| Overall Dimension(mm) | 5995×2300×2450 |
| Tyre Qty. | 6 |
| Tyre Spec. | 7.00R16LT 10PR |
| Wheelbase（mm） | 3600 |
| Front/Rear Overhang (mm) | 1110/1285 |
| Front/Rear Track (mm) | 1160/1235 |
| Approach/Departure angle(°) | 18/15 |
| Fuel Type | Diesel |
| Maximum Speed (km/h) | 95 |
| ABS | Included |
| Transmission | WLY 6-speed manual transmission |
| Steering | Power steering, hydraulic steering with power assistance |
| Cab | Mid-size cab (1880 series) Multi-functional steering wheel, cruise control, central locking, electric windows |
| Frame | 180mm double-layer reinforced beam |
| Primary Brake | Air brake system |
| Parking Brake | Air-spring parking brake (standard) |
Engine (Other Engine Optional) | |
| Brand | Weichai |
| Model | WP2.3Q140E62 |
| Power(kw) | 103 |
| Horsepower(HP) | 140 |
Upper & Equipment | |
| Load Capacity | 5 T |
| Flatbed Material | 5mm thick anti-slip patterned steel plate with thin-frame edges |
| Flatbed Length (mm) | 5600 |
| Winch System | 1 x 40KN (25m steel cable) |
| Hydraulic Flip Tail | Optional |
| Rear Tow Arm | Optional |
| Climate Control | Factory-installed air conditioning |
| Accessories | 4× New-Gen Tie-Down Straps, 2× L-Shaped Tire Holders, 2× Wheel Chocks，1× Chain Hook, 2× Trolleys, Toolbox |
| Remarks | Customized LOGO design as per customer needs! |
