1. Adopts Shacman specialized chassis and Cummins high-torque engine with ultra-high horsepower.
2. Equipped with a well-known domestic-brand gearbox featuring precise gear shifting and high transmission efficiency.
3. Tank capacity 15000L, Q235 high-quality carbon steel. All main tank welds strictly welded following non-destructive testing procedures.
4. Standard components: arc gear pump (pumping in/out capable); single compartment (multiple compartments customizable); one EU-standard tank port; one bottom valve with voice alarm; complete bottom loading system; full vehicle lightweight design,flow meter, high-flow fuel dispenser, 15-meter auto-rewind hose reel, and fuel nozzle.
Chassis | |
| Brand | Shacman |
| Drive Type | Left hand drive/4x2 |
| Gross Vehicle Weight(kg) | 18000 |
| Curb Weight(kg) | 7805 |
| Loading Weight(kg) | 10000 |
| Overall Dimension(mm) | 8600×2550×3300 |
| Tyre Qty. | 6 |
| Tyre Spec. | 295/80R22.5 18PR |
| Wheelbase（mm） | 4700 |
| Front/Rear Overhang (mm) | 1340/2560 |
| Approach/Departure angle(°) | 16/10 |
| Fuel Type | Diesel |
| Maximum Speed (km/h) | 79 |
| ABS | Yes |
| Transmission | 8-speed |
| Steering | Power steering, hydraulic steering with power assistance |
| Cab | Accommodate 2-3 people |
Engine(Other Engines Optional) | |
| Brand | Cummins |
| Model | B6.2NS6B245 |
| Power(kw) | 191 |
| Horsepower(HP) | 260 |
Upper Equipment | |
| Tank Capacity(cbm) | 15 |
| Tank Dimension(mm) | 6060×2200×1450 |
| Tank Material | Q235 Carbon steel |
| Tank Compartment Qty. | Single-chamber (Multiple-chamber Optional) |
| Tank Filling medium | Diesel or gasoline |
| Standard Components | Arc gear pump (pumping in/out capable); Single compartment (multiple compartments customizable); 1x EU-standard tank port; 1x bottom valve with voice alarm; Complete bottom loading system; Full vehicle lightweight design. Flow meter, high-flow fuel dispenser, 15-meter auto-rewind hose reel, and fuel nozzle |
| Other Services | Customized LOGO design as per customer needs! |
