1. Multi-brand professional refrigeration systems with energy-efficient cooling performance.
2. Composite-material insulated box structure with high-density thermal barrier technology.
3. Lightweight yet robust chassis combining high-strength steel and optimized load capacity.
4. Full-seal reinforced framework with corrosion-resistant alloy components.
5. Enhanced operational safety via active lighting systems and weatherproof engineering.
Chassis | |
| Brand | Foton |
| Drive Type | Left hand drive/4x2 |
| Gross Vehicle Weight(kg) | 4495 |
| Curb Weight(kg) | 2595 |
| Load Weight(kg) | 1770 |
| Overall Dimension(mm) | 5590×2070×2910 |
| Van Dimension(mm) | 3700×1850×1900 |
| Tyre Qty. | 6 |
| Tyre Spec. | 7.00R16LT |
| Wheelbase（mm） | 2900 |
| Front/Rear Overhang (mm) | 1115/1575 |
| Approach/Departure Angle(°) | 18/16 |
| Fuel Type | Diesel |
| Maximum Speed (km/h) | 110 |
| ABS | Included |
| Transmission | Wangliyang WLY5G32(4.71) ,5-speed |
| Steering | Power steering, hydraulic steering with power assistance |
| Cab | 2 persons |
Engine (Other Engines Optional) | |
| Brand | Quanchai |
| Model | Q23-132E60 |
| Power(kw) | 97 |
| Horsepower(HP) | 132 |
| Emission Standard | Euro 3 |
Upper & Equipment | |
| Cargo Box Construction | Thickened fiberglass, high-density insulation material, stainless steel corner guards, aluminum alloy trim (reinforced with steel sealed rivets) |
| Cargo Box Framework | Skeleton structure, all-wooden box body, broken bridge thermal insulation, 8cm insulation panels, lightweight high-strength steel sub-frame |
| Cargo Box Lighting | LED interior lamps, width indicator lights |
| Rear Door Frame Material | Thickened stainless steel |
| Door Seal | Black rubber seal (new 5-blade design with aluminum alloy edge strip) |
| Standard Configuration | Front drainage hole inside the cargo box; upper door handle; bolts, U-bolts, rubber-wire cushion pads, guard mesh, mudguards, 3M reflective adhesive strips |
| Refrigeration Unit | Optional globally recognized brands: Kerry, Hanyang, Thermo King, Carrier, etc. |
| Other Services | Customized LOGO design as per customer needs! |
