1.The sewage suction truck adopts an original Foton chassis with a Yunnei engine, offering strong power and, combined with a 10-ton vacuum pump(optional SK-12 water circulation pump), ensures performance under heavy loads and complex road conditions.
2.Equipped with a high-power vacuum pump, featuring strong suction and efficient operation, capable of quickly extracting various liquid, semi-liquid, and debris-containing media.
3.The tank structure is well-designed, utilizing one-time molding and dual-lift self-dumping, combined with an anti-overflow system to effectively enhance safety and durability.
4.Offers three functions: vacuum suction, pressure discharge, and gravity discharge, with an advanced pipeline system for simple operation and easy maintenance.
| Chassis | |
| Brand | Dongfeng |
| Drive Type | Left hand drive/4×2 |
| Gross Vehicle Weight(kg) | 16000 |
| Curb Weight(kg) | 7750 |
| Loading Weight(kg) | 8120,8055 |
| Overall Dimension(mm) | 7350,7150,7185,7210×2500,2550×3500,3550,3380 |
| Tyre Qty. | 6 |
| Tyre Spec. | 9.00R20 16PR,10.00R20 18PR,295/60R22.5 18PR |
| Wheelbase（mm） | 3950 |
| Front/Rear Overhang (mm) | 1450/1950,1250/1950,1285/1950,1310/1950 |
| Approach/Departure angle(°) | 15/14 |
| Fuel Type | Diesel |
| Maximum Speed (km/h) | 88 |
| ABS | Yes |
| Transmission | 6-Speed |
| Cab | 2-3 person |
| Engine(Other Engines Optional) | |
| Brand | Yunnei |
| Model | D43TCIF11 |
| Power(kw) | 151 |
| Horsepower(HP) | 205 |
| Upper Equipment | |
| Tank Capacity | 11.5m³/11.5CBM/11.5Ton/11500 L |
| Tank Overall Dimension(mm) | 4800×1800 |
| Tank Material | Optional with carbon/stainless steel alloy |
| Tank Thickness | Wall thickness 6mm,with internal anti-surge plates to enhance stability |
| Hydraulic System Pressure (MPa) | 18 |
| Rear Door System | The rear door opens hydraulically and is equipped with a mechanical locking device to ensure sealing and facilitate sewage dumping. |
| Self-Dumping Function | The tank can be lifted and self-dumped, enabling fast sewage discharge via a dual hydraulic cylinder system. |
| Rear Head Configuration | Equipped with a sewage inspection pipe at the top for monitoring the tank's interior status and a 100mm ball valve at the bottom as a discharge outlet. |
| Pump System | Equipped with a 10-ton vacuum pump (optional SK-12 water circulation pump), along with a water-oil separator, anti-overflow valve, and shock-resistant pressure gauge to ensure efficient suction and safe operation. |
| Auxiliary Devices | Standard configuration includes a hand-washing device, and powered side marker lights to meet daily operational needs. |
| Sewage Suction Hose | 1×8-meter |
| Other Services | Customized LOGO design as per customer needs! |
