1.Adopts Sinotruk G5 specialized chassis, 8x4 drive configuration with superior power.
2.Equipped with domestic Sinotruk HW13709XSTC2 gearbox, 9-speed manual gearbox featuring precise gear shifting and high transmission efficiency.
3.Tank capacity 27500L, high-quality carbon steel. Tank surface sandblasting treatment removes dust, contaminants, and rust, enhances paint thickness and adhesion. Baking paint process ensures pre-assembly + painting + final assembly, achieving full vehicle paint coverage without blind spots or omissions.
4.Standard components: arc gear pump (pumping in/out capable); single compartment (multiple compartments customizable); two EU-standard tank ports; one bottom valve; complete bottom loading system; full vehicle lightweight design,flow meter, high-flow fuel dispenser, 15-meter auto-rewind hose reel, and fuel nozzle.
Chassis | |
| Brand | CHNTC Group |
| Drive Type | Left hand drive/8x4 |
| Gross Vehicle Weight(kg) | 32000 |
| Curb Weight(kg) | 13470 |
| Loading Weight(kg) | 18400 |
| Overall Dimension(mm) | 11860×2550×3450 |
| Tyre Qty. | 12 |
| Tyre Spec. | 295/80R22.5 18PR |
| Wheelbase（mm） | 1800+4575+1400 |
| Front/Rear Overhang (mm) | 1450/2635 |
| Approach/Departure angle(°) | 16/10 |
| Fuel Type | Diesel |
| Maximum Speed (km/h) | 79 |
| ABS | Yes |
| Transmission | 9-speed |
| Steering | Power steering, hydraulic steering with power assistance |
| Cab | Accommodate 2-3 people |
Engine(Other Engines Optional) | |
| Brand | Sitrak |
| Model | MC07H.35-60 |
| Power(kw) | 257 |
| Horsepower(HP) | 350 |
Upper Equipment | |
| Tank Capacity(cbm) | 27.5 |
| Tank Dimension(mm) | 8800×2410×1610mm |
| Tank Material | Carbon steel |
| Tank Compartment Qty. | Single-chamber (Multiple-chamber Optional) |
| Tank Filling medium | Diesel or gasoline |
| Standard Components | Arc gear oil pump (capable of pumping in/out), Single compartment (customizable to multiple compartments), Complete bottom-loading system (including 1 bottom-loading/unloading valve, 1 vapor recovery valve, 1 vapor recovery interface, 1 set of pneumatic combination switch, 1 anti-overflow probe and 1 socket), 2x European-standard tank covers, 1x submerged valve, Voice prompt alarm device, Two oil delivery hoses, Two fire extinguishers Flow meter, high-flow fuel dispenser, 15-meter auto-rewind hose reel, and fuel nozzle |
| Other Services | Customized LOGO design as per customer needs! |
