1. Adopt Foton professional chassis and Quanchai high-torque engine, with a power output of up to 158 horsepower.
2. Equipped with WLY (Wanliyang) 6GS46 6-speed transmission for precise gear shifting.
3. Tank volume 7500 liters, carbon steel material with sandblasting and baking paint process to prevent rust and corrosion.
4. Standard accessories: Arc gear pump, one relief valve, one European standard tank port, one bottom valve, voice prompt device, a right-side-mounted lower oil discharge system, and lightweight design for the entire vehicle,flow meter, refueling machine, and hose reel.
Chassis | |
| Brand | Dongfeng |
| Drive Type | Left hand drive/4x2 |
| Gross Vehicle Weight(kg) | 9100 |
| Curb Weight(kg) | 3905 |
| Loading Weight(kg) | 5000 |
| Overall Dimension(mm) | 6260×2250×2700 |
| Tyre Qty. | 6 |
| Tyre Spec. | 7.50R16LT 16PR |
| Wheelbase（mm） | 3360 |
| Front/Rear Overhang (mm) | 1110/1790,1130/1770,1140/1760 |
| Approach/Departure angle(°) | 20/11 |
| Fuel Type | Diesel |
| Maximum Speed (km/h) | 80 |
| ABS | Yes |
| Suspension | 9/8+6 Leaf Spring Suspension |
| Other Configuration | Electric central control with Power Windows & remote door locks electric air conditioning Dual warning system with tire burst emergency response |
| Transmission | Wanliyang 6GS46, 6-speed |
| Steering | Power steering, hydraulic steering with power assistance |
| Cab | Auman MRT cab-1880 single row body, accommodate 2-3 people |
Engine(Other Engines Optional) | |
| Brand | Quanchai Power |
| Model | Q25A-160E60 |
| Power(kw) | 116 |
| Horsepower(HP) | 158 |
Upper Equipment | |
| Tank Capacity(cbm) | 7.5 |
| Tank Dimension(mm) | 4000×1850×1250 |
| Tank Material | Carbon steel |
| Tank Thickness(mm) | 4.2 |
| Tank Compartment Qty. | Single-chamber design |
| Tank Filling medium | Diesel or gasoline |
| Standard Components | HY-40 arc gear pump, 1× relief valve, 1× European standard tank port, 1× bottom loading valve (emergency shut-off), Voice alert module Bottom loading system (mounted on the right side) Flow meter, refueling machine, and hose reel |
| Other Services | Customized LOGO design as per customer needs! |
