1. FAW chassis equipped with a 240 horsepower engine + 8-speed gearbox, providing strong power and meeting the high-efficiency transport needs of recovery vehicles.
2. The superstructure is equipped with a 10-ton, three-section rear tow arm + imported hydraulic system + sunken 6mm patterned plate flatbed, integrating a tilting tailboard,enhancing multi-functional recovery capabilities.
3. Equipped with an XCMG 8-ton, four-section folding arm crane, combined with a 10-ton winch system and auxiliary trolley, enabling high-altitude lifting and heavy-duty rescue joint operations.
4. Comprehensive intelligent safety configuration, including electronic speed limit of 89km/h, ABS braking, fire extinguishers, and driver alarm systems, ensuring that the entire operation process is controllable.
Chassis | |
| Brand | FAW |
| Drive Type | 4x2,LHD/RHD |
| Gross Vehicle Weight(kg) | 18000 |
| Curb Weight(kg) | 15000 |
| Overall Dimension(mm) | 10570×2500×3880 |
| Tyre Qty. | 6 |
| Tyre Spec. | 10.00R20 18PR |
| Wheelbase（mm） | 5700 |
| Front/Rear Overhang (mm) | 1332/3495 |
| Approach/Departure angle(°) | 21/10 |
| Fuel Type | Diesel |
| Maximum Speed (km/h) | 89 |
| ABS | Included |
| Transmission | 8-speed |
| Cab | 2-3 person |
| Frame | 10/12+8 |
Engine (Other Engine Optional) | |
| Brand | FAW |
| Model | CA6DK1-24E6 |
| Power(kw) | 178 |
| Horsepower(HP) | 240 |
Upper & Equipment | |
| Max Load Capacity | 16 Ton |
| Fuel Tank Capacity(L) | 200 |
| Auxiliary Configs | Electrically heated rearview mirrors, and dual air intake ports. |
| Towing System | 10-ton vehicle, the flatbed adopts a sunken design, equipped with a 6mm thick anti-slip patterned plate, and an optional integrated hydraulic flip tailgate at the rear. |
| Rescue Toolkit | Standard configuration includes tire clamping device, two pairs of towing forks, L-shaped towing forks, 6 straps, and rotating cylinder, 10-ton winch with 25-meter steel wire rope |
| Crane | XCMG 8-ton, 4-section folding arm crane, with a four-section arm design, the full extension length reaches 15.8 meters, and the maximum lifting height is 31.5 meters. Imported multi-way valve drive, crane rotation angle 360°, supports wireless remote control operation, single rope maximum tensile force is 8 tons, crane positioning accuracy error ≤ 5cm |
| Remarks | Customized LOGO design as per customer needs! |
