1.Large capacity tank with dimensions of 9150×2500×2655 mm, made from durable Q235 carbon steel.
2.Strong chassis configuration with 8x4 drive type and 4 axles, supporting a gross vehicle weight of 31,000 kg.
3.Reliable XICHAI engine, delivering 268 kW (365 HP) and compliant with Euro 3 emission standards.
4.Standard configuration includes pump, motor, operation box, and ladder for efficient feed handling.
5.Comfortable cabin for 3 passengers, equipped with air conditioning, electric windows, and central locking.
| Chassis | |
| Drive Type | LHD or RHD /8x4 |
| Gross Vehicle Weight(kg) | 31000 |
| Curb Weight(kg) | 15540 |
| Overall Dimension(mm) | 12000×2550×3998 |
| Tyre Qty. | 12+1 spare |
| Tyre Spec. | 12R22.5,295/80R22.5 |
| Wheelbase（mm） | 1900+4700+1350 |
| Number Of Axles | 4 |
| Axle Loading (kg) | 6500/6500/18000/18000 |
| Fuel Type | Diesel |
| Maximum Speed (km/h) | 89 |
| Transmission | 10 forwarder with 1 Reverse |
| Cab | 3 passengers,air conditioning, electric doors and windows, central locking, electric rearview mirrors |
| Engine (Other Engine Optional) | |
| Brand | XICHAI |
| Cylinder Qty. | 6 |
| Emission Standard | Euro 3 |
| Cylinder Arrangement | Inline |
| Power(kw) | 268 |
| Horsepower(HP) | 365 |
| Upper & Equipment | |
| Tank Dimension(mm) | 9150×2500×2655 |
| Tank Capacity | 32cbm/32m³ |
| Tank Material | Carbon steel Q235 |
| Standard configuration | Pump, motor, operation box, ladder. |
| Remarks | Customized LOGO design as per customer needs! |
