1. The vehicle adopts a FAW hazardous chemical-specific chassis structure, paired with a low-speed, high-torque Xichai engine and a Shaanxi 8-speed manual transmission that balances heavy-load starting and fuel efficiency.
2. It adopts front disc and rear wedge brakes with EBS, combined with imported AEBS (Automatic Emergency Braking) + ESC (Electronic Stability Control) + LDWS (Lane Departure Warning System) + FCW (Forward Collision Warning) to achieve full-scenario intelligent safety braking.
3. The tank body is made of Q235 high-quality carbon steel plate, lined with polyethylene material and equipped with PTFE-lined ball valves for dual protection against hydrochloric acid corrosion, along with smart alarms, emergency shut-off, and fireproof devices to form multiple protective layers.
4. It adopts the liquid level differential gravity self-flow or external temporary pump method for loading/unloading through the rear self-flow outlet and DN65 PTFE-lined ball valve. The pump-free design avoids pump body corrosion and leakage risks, making it highly suitable for transporting highly corrosive media in chemical plants and storage bases.
Chassis | |
| Brand | FAW |
| Drive Type | Left hand drive/6x4 |
| Gross Vehicle Weight(kg) | 25500 |
| Curb Weight(kg) | 9800 |
| Loading Weight(kg) | 15505 |
| Overall Dimension(mm) | 9350×2520×3400 |
| Tyre Qty. | 8 |
| Tyre Spec. | 295/80R22.5 18PR |
| Wheelbase（mm） | 1900+4000 |
| Front/Rear Overhang (mm) | 1332/2118 |
| Approach/Departure angle(°) | 21/12 |
| Fuel Type | Diesel |
| Maximum Speed (km/h) | 80 |
| ABS | Yes |
| Transmission | 5-speed |
| Steering | Power steering, hydraulic steering with power assistance |
| Cab | Accommodate 2-3 people |
Engine(Other Engines Optional) | |
| Brand | FAW |
| Model | CA6DLD-22E6 |
| Power(kw) | 164 |
| Horsepower(HP) | 223 |
Upper Equipment | |
| Tank Capacity(cbm) | 14.2 |
| Tank Dimension(mm) | 6750×1770 |
| Tank Material | Q235 carbon steel |
| Tank Compartment Qty. | Single-chamber |
| Tank Filling medium | Hydrochloric acid |
| Standard Components | 1× all-plastic tank ports; 2×Breathing valve; 1× Bottom valve; 1× Emergency shut-off valve; 1×Voice prompt alarm system; 2× DN65 PTFE-lined ball valves; 1×Tool kit; 2× hoses for liquid transfer; 2× fire extinguishers; 1× flame arrester; 1×Top guardrails; 1×Rear access ladder; |
| Other Services | Customized LOGO design as per customer needs! |
